Hardware Specifications

RG-PF2920U-4GT1MS-P

RG-PF2920-DPBOX-P

Fixed ports

4 x 10M/100M/1000M auto-negotiation electrical ports

1 x 1000M/2.5G SFP port

1 x 10M/100M/1000M auto-negotiation electrical port

1 x GE SFP port

Switching capacity

13 Gbps

N/A

Packet forwarding rate

9.7 Mpps

N/A

SFP port

2500Base-X and 1000Base-X supported

1000Base-X supported

Power supply

Powered by a hybrid cable from the PoF switch

Maximum voltage range: 42 V DC to 57 V DC

Rated voltage range: 44 V DC to 56 V DC

Rated current: 1.3 A

Powered by a hybrid cable from the PoF switch

Rated voltage: 44 V DC to 57 V DC

Rated current: 0.75 A

Leakage current to ground

≤ 3.5 mA

N/A

EEE

Supported

Not supported

PoE

Ethernet electrical ports 1–4 support PoE.

Max. overall PoE output power: 60 W

The maximum number of PoE devices supported by the switch is determined by the PoE output power of the switch and the actual power of the PoE devices.

1 x downlink POE/POE+ port

Overall power consumption

Without PoE load: ≤ 15 W

With PoE full load: ≤ 75 W

Without PoE load: ≤ 3 W

Overall power (PoE+) ≤ 33 W

Operating temperature

Installed in a rack or unconfined space: 0ºC to 45ºC (32ºF to 113ºF) at a height below 1,800 m (1.12 miles) above the sea level

Installed on a workbench or in an ELV box: 0ºC to 40ºC (32ºF to 104ºF) at a height below 1,800 m (1.12 miles) above the sea level

Note: At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum operating temperature decreases by 1°C (1.8°F) for every increase in altitude of 220 m (721.78 ft.).

Installed in a rack or unconfined space: 0ºC to 45ºC (32ºF to 113ºF) at a height below 1,800 m (1.12 miles) above the sea level

Installed on a workbench or in an ELV box: 0ºC to 40ºC (32ºF to 104ºF) at a height below 1,800 m (1.12 miles) above the sea level

Note: At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum operating temperature decreases by 1°C (1.8°F) for every increase in altitude of 220 m (721.78 ft.).

Storage temperature

–40°C to +70°C (–40ºF to +158ºF)

–40°C to +70°C (–40ºF to +158ºF)

Operating humidity

10% to 90% RH

10% to 90% RH

Storage humidity

5% to 90% RH

5% to 95% RH

Fan

Fanless design, natural cooling

Fanless design, natural cooling

Intelligent temperature control

The temperature alarm and overheat protection functions are supported.

Not supported

Electromagnetic compatibility (EMC)

GB/T9254.1

GB/T9254.1

Safety standard

GB 4943.1

GB 4943.1

Dimension (W x D x H)

200 mm x 170 mm x 55 mm (7.87 in. x 6.69 in. x 2.17 in.)

120 mm x 25 mm x 40 mm (4.72 in. x 0.98 in. x 1.57 in.)

Weight

1.5 kg (3.30 lbs, including the package)

0.2 kg (0.44 lbs, including the package)

Software Specifications

RG-PF2920U-4GT1MS-P

RG-PF2920-DPBOX-P

802.1Q VLAN

4K IEEE 802.1Q VLANs

Port-based VLAN

Not supported

DHCP

DHCP client

Not supported

Security

Filtering of invalid MAC addresses

Broadcast storm suppression

Password protection

CPP

Port protection

Not supported

EEE

APD port sleeping

Not supported

Management

CLI-based configuration and management not required, visualized Web management

IoT MQTT

Syslog/Debug and SNTP

Not supported
